Breaking wind news. Do not worry about methane.

Break wind is the habit of cows,

far more than clean air act allows.

Let’s collect all their gas,

give the cows some pizzazz;

the food a methanotrop chows.



Gretacowbreak



Fear not, dear Greta: This is the solution.

On second thought it isn’t. Methane, even if it is a much stronger greenhouse gas than even CO2 when analyzed by itself , is an irrelevant gas.

Water vapor has already absorbed the very same infrared radiation that Methane might have absorbed. (You cannot absorb more than 100% of the radiation emitted in any given band)

Guest essay by Dr. Tom Sheahen

Q: I read that methane is an even worse greenhouse gas than carbon dioxide, and cattle are a big source of methane emissions. How are they going to regulate that? Not just cattle, but dairy cows as well! That doubles the worry.

Fortunately, there is really nothing to worry about, scientifically. The main thing to worry about is over-reacting politicians and another layer of unnecessary government regulations.

To understand methane’s role in the atmosphere, first it’s necessary to understand what absorption means. When light passes through a gas (sunlight through air, for example), some molecules in the gas might absorb a photon of light and jump up to an excited state. Every molecule is capable of absorbing some particular wavelengths of light, and no molecule absorbs all the light that comes along. This holds true across the entire electromagnetic spectrum – microwave, infrared, visible, and ultraviolet.

The process of absorption has been studied in great detail. In a laboratory set-up, a long tube is filled with a particular gas, and then a standard light is set up at one end; at the other end of the tube is a spectrometer, which measures how much light of each wavelength makes it through the tube without being absorbed. (Mirrors are placed so as to bounce the light back and forth several times, making the effective travel path much longer; this improves the precision of the data.) From such measurements, the probability of radiation being captured by a molecule is determined as a function of wavelength; the numerical expression of that is termed the absorption cross-section.

If you carried out such an experiment using ordinary air, you’d wind up with a mixture of results, since air is a mixture of various gases. It’s better to measure one pure gas at a time. After two centuries of careful laboratory measurements, we know which molecules can absorb which wavelengths of light, and how likely they are to do so.

All that data is contained in charts and tables of cross-sections. Formerly that meant a trip to the library, but nowadays it’s routinely downloaded from the internet. Once all the cross-sections are known, they can be put into a computer program and the total absorption by any gas mixture (real or imaginary) can be calculated.

The many different molecules absorb in different wavelength regions, known as bands. The principal components of air, nitrogen and oxygen, absorb mainly ultraviolet light. Nothing absorbs in the visible wavelength range, but there are several gases that have absorption bands in the infrared region. These are collectively known as the GreenHouse Gases (GHG), because absorbing infrared energy warms up the air – given the name greenhouse effect.

The adjacent figure shows how six different gases absorb radiation across the infrared range of wavelengths, from 1 to 16 microns (mm). The vertical scale is upside-down: 100% absorption is low, and 0% absorption (i.e., transparency) is high.

methane_absorption_spectra

It’s important to realize that these are shown on a “per molecule” basis. Because water vapor (bottom bar of the figure) is much more plentiful in the atmosphere than any of the others, H­2O absorbs vastly more energy and is by far the most important greenhouse gas. On any given day, H2O is a percent or two of the atmosphere; we call that humidity.

The second most important greenhouse gas is carbon dioxide (CO2), which (on a per-molecule basis) is six times as effective an absorber as H2O. However, CO2 is only about 0.04% of the atmosphere (400 parts per million), so it’s much less important than water vapor.

Now it’s necessary to scrutinize the figure very carefully. Looking across the wavelength scale at the bottom, H2O absorbs strongly in the 3-micron region, and again between 5 and 7 microns; then it absorbs to some degree beyond about 12 microns. CO2 has absorption bands centered around 2.5 microns, 4.3 microns, and has a broad band out beyond 13 microns. Consequently, CO2 adds a small contribution to the greenhouse effect. Notice that sometimes CO2 bands overlap with H2O bands, and with vastly more H2O present, CO2 doesn’t matter in those bands.

Looking at the second graph in the figure, methane (CH4) has narrow absorption bands at 3.3 microns and 7.5 microns (the red lines). CH4 is 20 times more effective an absorber than CO2in those bands. However, CH4 is only 0.00017% (1.7 parts per million) of the atmosphere. Moreover, both of its bands occur at wavelengths where H2O is already absorbing substantially. Hence, any radiation that CH4 might absorb has already been absorbed by H2O. The ratio of the percentages of water to methane is such that the effects of CH4 are completely masked by H2O. The amount of CH4 must increase 100-fold to make it comparable to H2O.

Because of that, methane is irrelevant as a greenhouse gas. The high per-molecule absorption cross section of CH4 makes no difference at all in our real atmosphere.

Unfortunately, this numerical reality is overlooked by most people. There is a lot of misinformation floating around, causing needless worry. The tiny increases in methane associated with cows may elicit a few giggles, but it absolutely cannot be the basis for sane regulations or national policy.

So, dear Greta, go back to school and learn some physics, some chemistry, and learn how nature really functions. Then you would not be as worried any more. There is a great temperature regulator, called water vapor. Yes, water vapor is the most important greenhouse gas, and without it the earth would be so cold that no life would be possible. Not only that, but water vapor is a condensing gas, and it forms clouds, which are the main regulator of temperature here on earth.

Have you ever noticed that it is cooler in the shadow?

And by the way, what are methanotrop bacteria?

Methane-utilizing bacteria (methanotrophs) are a diverse group of gram-negative bacteria that are related to other members of the Proteobacteria. These bacteria are classified into three groups based on the pathways used for assimilation of formaldehyde, the major source of cell carbon, and other physiological and morphological features. The type I and type X methanotrophs are found within the gamma subdivision of the Proteobacteria and employ the ribulose monophosphate pathway for formaldehyde assimilation, whereas type II methanotrophs, which employ the serine pathway for formaldehyde assimilation, form a coherent cluster within the beta subdivision of the Proteobacteria. Methanotrophic bacteria are ubiquitous. The growth of type II bacteria appears to be favored in environments that contain relatively high levels of methane, low levels of dissolved oxygen, and limiting concentrations of combined nitrogen and/or copper. Type I methanotrophs appear to be dominant in environments in which methane is limiting and combined nitrogen and copper levels are relatively high. These bacteria serve as biofilters for the oxidation of methane produced in anaerobic environments, and when oxygen is present in soils, atmospheric methane is oxidized. Their activities in nature are greatly influenced by agricultural practices and other human activities. Recent evidence indicates that naturally occurring, uncultured methanotrophs represent new genera. Methanotrophs that are capable of oxidizing methane at atmospheric levels exhibit methane oxidation kinetics different from those of methanotrophs available in pure cultures. A limited number of methanotrophs have the genetic capacity to synthesize a soluble methane monooxygenase which catalyzes the rapid oxidation of environmental pollutants including trichloroethylene.

Sounds excitig, doesn’t it. Harvesting methane, put it into warm water (about 45C) and let the bacteria do their job, producing fish food. It may even be profitable.



Published by

lenbilen

Engineer, graduated from Chalmers Technical University a long time ago with a degree in Technical Physics. Career in Aerospace, Analytical Chemistry, and chip manufacturing. Presently adjunct faculty at PSU, teaching one course in Computer Engineering, the Capstone Course.
